Description:
1、Transparent tank body: The tank body has an overall structural design, which is beautiful and sturdy
2、Large arc angle: There will be no adverse phenomena such as gap leakage, material storage dead corners, etc. during use
3、Tank wall thickness: convenient opening and sealing of the filling port, tightly sealed to prevent material leakage
4、High quality: reasonable structure, light weight, beautiful appearance, convenient loading and unloading of materials, convenient sealing and opening of filling ports, good wear resistance
5、High precision: The tank body has thick walls, is sturdy and durable, has a long service life, low noise, and is not easily contaminated by grinding materials
Dimension:(unit:mm)
Volume
Dimension
Internal diameter
Outside diameter
Thickness
50ml
72*72*58/90
47
72
12.5
100ml
83*83*68/100
52
83
15.5
250ml
108*108*93/125
80
108
14
500ml
125*125*107/139
89
125
18
1000ml
160*160*126/157
115
160
22.5
